Parking this info here for my future-self to reference.
Create a vim file, mine is at ~/gitcommithighlight.vim
:highlight OverLength ctermbg=red ctermfg=white guibg=red
" First line must be 50 characters or less
:let w:m1=matchadd('OverLength', '\%1l\%>50v.\+', -1)
" Second line must be blank
:let w:m1=matchadd('OverLength', '\%2l\%>0v.\+', -1)
" All other lines must be be 72 characters or less
:let w:m2=matchadd('OverLength', '\%>2l\%>72v.\+', -1)
Set git’s editor to vim and make it source the above file: git config --global core.editor "$(which vim) -S ~/gitcommithighlight.vim"
So I’ve been thinking for a while, “wifi control of these lamps is all well and good, but I’d really rather push data over a serial connection so that I can avoid having to set up wifi networks. Also, serial just makes more sense for high throughput usecases, eg sending a continuous stream of updates”
“…Too bad WLED doesn’t have a serial API”
You know what they say about when you assume things? I don’t know why I never really looked it up, but I just figured that WLED didn’t have serial support. Turns out it actually supports multiple protocols, and as of 0.13.0 it can receive the same JSON commands via serial as it does via wifi.
So here’s a little video of a proof of concept I put together, to learn a couple of things. It’s my first time playing around with web serial – I lifted heavily from this Codelab to get things working.
Oh boy, let me take you down the rabbit hole that keeps sneakily stealing hours of my life from me.
We’ll start with a topic I’ve covered a few times before:
Seals
I’ve written before about my mock sinograph signature – a pseudo Chinese-character sequence that I use to sign my artwork with.
Inktober piece with the latest version of my calligraphic sinograph
I have also signed my work in the past with a signature stamp that I picked up at a dollar store in Japan, that simply contained the character of my surname.
The first artwork I can find that uses the 林 stamp.
In the intervening times, I’ve experimented with laser engraving seals of my sinograph, and modifying its design. I briefly hit on a design I absolutely adored that incorporated “Alethea” into the character 鴨 (duck), which when put together with my surname 林 would have correspondingly given me “forest duck” as my signature. This would allude to the name of the chenonetta jubata in Chinese, nicely tying all of my identities together.
Seal script version of 林鴨
Unfortunately, a Mandarin-speaking coworker cautioned me against using 鴨 as a pseudonym. They informed me that when referring to people, “duck” is sometimes used as a euphemism for a male prostitute. So with that knowledge, I decided to fall back to my made-up characters.
Only a couple of pieces were signed with the calligraphic version of this signature before I reverted to my older signature.
When I made the most recent revision to my signature, I decided to get it professionally carved into soapstone, and had the company confirm that I wasn’t going to run into any similar embarrassing misunderstandings with the design. The actual seal carving ended up being very expensive (considering I could have just laser engraved it myself), but I valued the peace of mind that came with having someone knowledgable vetting it. Experiencing how the seal design transferred so cleanly with good quality seal paste (the ink used to stamp the blocks with) also unlocked the next step in my journey.
Soapstone chop and the stamped design
QArt Codes
Some time ago, I read this blog post about embedding images into QR codes. As a tl;dr, QR codes are made to be tolerant to damage. Most QR codes that contain logos in them just cover the data contained in the code and take advantage of the error-correcting algorithm to ensure the right values are read out. “QArt Codes”, on the other hand, use a provided image to generate a URL that naturally encodes to something that resembles the source image.
I can’t remember what led me to the article initially, it was a looooong time ago. I may have been working on a puzzle hunt for AVCon that used QR codes to log people’s progress and I wanted to embed the AVCon Invader logo into it (so some time around 2014). But the puzzle hunt, and QR codes in Aus generally didn’t catch on so the idea just got relegated to the back of my mind.
Still, QArt codes are super neat and I’m surprised I haven’t seen them in the wild more. Actually, I think the page that generated the codes was down during the rise of QR codes in the pandemic, so there was a bit of a missed window. But the page is back now, and you can play with making your own! Or if you want to play with the code there’s a standalone version you can run locally.
(Side note, when I was researching game-parsing screen readers to work on Ikalog stuff, I ran into this blog post by Up Banking. That’s the only QArt code that I’ve recognised in the wild to date)
Adding 2+2…
This is the post that lit the lightbulb in my head.
What do you guys think about the possibility of artists using small QR code’s as watermarks to link back to the artist? pic.twitter.com/9gk3a6GHhK
I mean, having hit this point in my post it’s pretty obvious what we’re gonna do, right?
QArt Chopping and Changing
“So how did you lose hours of your life to this? There’s a page that generates them, you just put your picture in there and you’re done, right?”
Well, to start off with, as I mentioned above the page that generates them was actually not available for some time, so I had to mess around with the original QArt source code (with a few headaches) and then later had the fortune of running into the standalone version.
After that… I lost time to the search of perfection.
Here’s my first draft of a painterly QArt signature. The output of the QArt generator still had a lot of noise, so I used painterly brushstrokes to make the noise look more appealing. At this point I still only superficially appreciated the stuff in the article and while I knew about some areas that were more important to preserve than others I was mostly just drawing willy-nilly with the understanding that “QR codes can repair damaged data”.
It’s neat but it’s off-centre, it contains only my surname and it probably won’t scan properly when scaled down for overlaying on art.
I was satisfied for a while with the proof of concept, but later I started thinking about laser cutting myself a new signature chop anyway, as the soapstone one I’d purchased was too large to use on A4 and smaller art (the majority of my pieces!)
So I looked at the QR codes and realised that I should provide a source image that wouldn’t need to scale. I want to control the pixels of the code so I should provide a pixel art version of my signature.
Something like this. The QArt generator will try to respect the original colours of the pixels, but it almost always has to make compromises. The generator will put priority on preserving areas with full alpha, and will relegate its manipulations to transparent areas in the source image.
This provides an okayish output – it’s a good basis on which to paint over parts to arrive at a more aesthetically pleasing version.
I did do some test runs with this kind of “corrected” design and to my delight they did scan when stamped.
The seal paste that I originally got with my soapstone seal proved an excellent transfer medium for the design
However, I anticipate that the stamping process can be error prone and therefore it will be impossible to perfectly transfer the design. So I keep returning to these QArt codes to try to minimise the errors. First by lowering the amount of modifications that I make to the generated code…
Here’s a really tiny version where did some painting over the generated code but compromised a bit towards the lower area of the design.
Then, by changing the generation of the code itself.
One strategy was to reduce the area of the QR code that must be dedicated to my URL. I chose not to use a URL shortener. I intend to keep the chenonetta.com domain into the forseeable future but I can’t control what happens with any URL forwarding services.
I also opted to include the full http:// prefix in the URL. I did some playing around with readers and some automatically open pages if the URL starts with www. or ends with a .com but I didn’t want to rely on that behaviour. I kept the ale subdomain but that’s the least defensible decision and I might change my mind on it in the future.
So how to save space if I’m not shortening the input data? The original QArt coder uses byte encoding for the main part of the URL. This uses 8 bits per character. I modified the generator to create the URL in two parts – an alphanum encoded section for the main URL and then byte encoding just for the # that joins the URL and its throwaway anchor. Alphanumeric encoding uses 11 bits for every two characters. Overall I did still save a little space, even with the extra stuff needed to define the single-character byte encoded section.
I also played with manually specifying the masking strategy (the mask is a pattern that gets XOR’d over the generated QR code – read the original QArt code article for details).
After a lot of iterating, this is probably the closest I’ll get for now. I think this is technically still a damaged code but the areas that I drew through are part of the instructions about how to read the code, not the data. Like the data itself, there are some redundancies for the instructions so the codes still scan ok. Most of the time I’ve spent on these codes has been spent in the cleanup and tweaking stages – what can I get away with without introducing errors?
This is supposedly an error free code according this debugging website – though the scale of the source image definitely affects its assessment of whether the code is error free or not. The site also doesn’t recognise flipped QR codes (even though other readers seem to be fine with them)
Working on the flipped design is kind of convenient because it’s how the plastic will be engraved for printing.
Being forced to make compromises on the final outcome always keeps me coming back to tweak things again and again – can I change the orientation so that I don’t have to use a flipped code? Can I rebalance the density of noise around the main design so that it doesn’t distract from the centre as much? Can I smooth the curves in the image more? I’ll just keep searching and searching for the ideal version of this design…
To wrap up, here’s the current setup I use for transferring the print to paper. I’ve been experimenting with moving to block printing ink instead of seal paste, because the latter is oil based and takes days to dry. So far I haven’t had a high success rate with the new ink but I think I’m learning. Sometimes a dodgy print can be recovered with a little bit of hand editing, though it requires some deft brushwork!
The seal, the artwork and a folded piece of kitchen paper are clamped to a table.
Follow these steps to set up WLED colour changes as channel point rewards using Kruiz Control. These instructions are written specifically for my Squid Lamps but can be modified for use with any WLED project.
Click the above link to generate a token. You’ll be prompted to authorize permissions as a Twitch account.
Do not share this token with anyone else! It has permissions to manage your channel redemptions, to send messages in chat as the Twitch account that you choose and to see the email associated with the account. (I dunno why email address is needed but Comfy.js won’t work without that permission)
Open settings/chat/oauth.txt and replace the “token” part of the file with the generated token. Remove any spaces.
Channel Name
In settings/twitch/user.txt set the name of the channel that you want to watch for channel point redemptions. (Usually, your channel)
Chat User (Optional – not currently used)
Set settings/chat/user.txt to a Twitch channel. Setting this would allow Kruiz Control to send messages on your behalf to that channel.
Replace the contents of triggers.txt with the following. Note that the OnChannelPoint triggers need to match the names of the rewards from the step above.
Replace the IP address on line 2 (http://192.168.0.113) with the IP of the lamp.
Your lamp needs to be connected to the same network as your streaming PC.
OnInit
API Url SquidBeakon "http://192.168.0.113/json/state"
API Method SquidBeakon POST
API Header SquidBeakon "Content-Type" "application/json"
OnChannelPoint "Rainbow Lamp"
API RawData SquidBeakon "{\"seg\": [{\"of\": 4, \"fx\": 110, \"sx\": 128, \"ix\": 128, \"pal\": 11}]}"
API Send SquidBeakon
OnChannelPoint "Blue Lamp"
API RawData SquidBeakon "{\"seg\": [{\"fx\": 0, \"col\": [[0, 0, 255]]}]}"
API Send SquidBeakon
OnChannelPoint "Cyan Lamp"
API RawData SquidBeakon "{\"seg\": [{\"fx\": 0, \"col\": [[0, 255, 200]]}]}"
API Send SquidBeakon
OnChannelPoint "Green Lamp"
API RawData SquidBeakon "{\"seg\": [{\"fx\": 0, \"col\": [[8, 255, 0]]}]}"
API Send SquidBeakon
OnChannelPoint "Yellow Lamp"
API RawData SquidBeakon "{\"seg\": [{\"fx\": 0, \"col\": [[255, 200, 0]]}]}"
API Send SquidBeakon
OnChannelPoint "Orange Lamp"
API RawData SquidBeakon "{\"seg\": [{\"fx\": 0, \"col\": [[255, 160, 0]]}]}"
API Send SquidBeakon
OnChannelPoint "Red Lamp"
API RawData SquidBeakon "{\"seg\": [{\"fx\": 0, \"col\": [[255, 0, 0]]}]}"
API Send SquidBeakon
OnChannelPoint "Magenta Lamp"
API RawData SquidBeakon "{\"seg\": [{\"fx\": 0, \"col\": [[255, 0, 255]]}]}"
API Send SquidBeakon
Once this is implemented, we can update the trigger code to refund channel points if the lamp failed to update, and clear items out of the queue if it’s successful.
Alternatively, we could write our own code using Comfy.js!
Add a new browser source. Select “Local File” and pick the index.html file from the Kruiz Control directory that you extracted in step 1. Keeping this browser source active will listen for Channel Point redemptions.
Select a reward in Twitch and if everything has been set up correctly, the lamp colours will change!
If you make any changes to the files inside the Kruiz Control directory, including the settings or triggers.txt files, you must refresh your browser source in OBS for the changes to take effect.
Appendix: A single reward with user-provided colour
If you don’t want to crowd your rewards with the lamp options, you can create one reward and allow it to control the lamp colours with the redemption message from your viewers.
Using a single reward also allows for the Twitch cooldowns to be used. This means that a viewer can’t override the colours set by another viewer until the cooldown ends.
Replace triggers.txt with the text from the code block below. Create a single reward named “Set Lamp Color” and turn on the “Require Viewer to Enter Text” checkbox.
This trigger will search the text of the message that was attached to the points redemption and if one of the color keywords is found then the lamp colour will change. It’s worth suggesting to the user what to enter in their message in the reward description, eg:
Set my squid lamp to rainbow, blue, cyan, green, yellow, orange, red or magenta by including one of these words in your message!
OnInit
API Url SquidBeakon "http://192.168.0.113/json/state"
API Method SquidBeakon POST
API Header SquidBeakon "Content-Type" "application/json"
OnChannelPoint "Set Lamp Color"
Param Lower message
Param Keyword message "rainbow"
If 3 {matched} == true
API RawData SquidBeakon "{\"seg\": [{\"of\": 4, \"fx\": 110, \"sx\": 128, \"ix\": 128, \"pal\": 11}]}"
API Send SquidBeakon
Exit
Param Keyword message "blue"
If 3 {matched} == true
API RawData SquidBeakon "{\"seg\": [{\"fx\": 0, \"col\": [[0, 0, 255]]}]}"
API Send SquidBeakon
Exit
Param Keyword message "cyan"
If 3 {matched} == true
API RawData SquidBeakon "{\"seg\": [{\"fx\": 0, \"col\": [[0, 255, 200]]}]}"
API Send SquidBeakon
Exit
Param Keyword message "green"
If 3 {matched} == true
API RawData SquidBeakon "{\"seg\": [{\"fx\": 0, \"col\": [[8, 255, 0]]}]}"
API Send SquidBeakon
Exit
Param Keyword message "yellow"
If 3 {matched} == true
API RawData SquidBeakon "{\"seg\": [{\"fx\": 0, \"col\": [[255, 200, 0]]}]}"
API Send SquidBeakon
Exit
Param Keyword message "orange"
If 3 {matched} == true
API RawData SquidBeakon "{\"seg\": [{\"fx\": 0, \"col\": [[255, 160, 0]]}]}"
API Send SquidBeakon
Exit
Param Keyword message "red"
If 3 {matched} == true
API RawData SquidBeakon "{\"seg\": [{\"fx\": 0, \"col\": [[255, 0, 0]]}]}"
API Send SquidBeakon
Exit
Param Keyword message "magenta"
If 3 {matched} == true
API RawData SquidBeakon "{\"seg\": [{\"fx\": 0, \"col\": [[255, 0, 255]]}]}"
API Send SquidBeakon
Exit
Appendix: Customising Eye colours
Add the following trigger commands to triggers.txt. Make sure to create the corresponding rewards in the Twitch dashboard!
OnChannelPoint "Red Eyes"
API RawData SquidBeakon "{\"seg\": [{},{\"col\": [[255, 0, 0]]}]}"
API Send SquidBeakon
OnChannelPoint "Lime Eyes"
API RawData SquidBeakon "{\"seg\": [{},{\"col\": [[255, 255, 0]]}]}"
API Send SquidBeakon
OnChannelPoint "White Eyes"
API RawData SquidBeakon "{\"seg\": [{},{\"col\": [[255, 255, 255]]}]}"
API Send SquidBeakon
Appendix: Multiple Lamps
This sample sets up SquidBeakon1 and SquidBeakon2 with their own URLs so that they can be driven by separate rewards. Full support for multiple channel point settings is left as an exercise for the reader.
OnInit
API Url SquidBeakon1 "http://192.168.0.113/json/state"
API Method SquidBeakon1 POST
API Header SquidBeakon1 "Content-Type" "application/json"
API Url SquidBeakon2 "http://192.168.0.114/json/state"
API Method SquidBeakon2 POST
API Header SquidBeakon2 "Content-Type" "application/json"
OnChannelPoint "Rainbow Lamp 1"
API RawData SquidBeakon1 "{\"seg\": [{\"of\": 4, \"fx\": 110, \"sx\": 128, \"ix\": 128, \"pal\": 11}]}"
API Send SquidBeakon1
OnChannelPoint "Rainbow Lamp 2"
API RawData SquidBeakon2 "{\"seg\": [{\"of\": 4, \"fx\": 110, \"sx\": 128, \"ix\": 128, \"pal\": 11}]}"
API Send SquidBeakon2
Appendix: Tips for displaying your lamps on stream
The lamps are emitting light, which can be difficult to capture on camera. Some tips to improve the appearance of the lights:
Reflected surfaces
Nearby white or other reflective surfaces will convey the colours of the light
Ambient lighting
The lights will be washed out by bright ambient lighting. The frequencies of sunlight can be especially effective at washing out the lamp colours. Indoor lighting or a dimmed room are best!
Diffusion
A piece of printer paper or baking paper in front of the lights can be used to diffuse the colours. This file contains templates for paper cutouts that can be placed in or on the lamp.
WLED JSON API
The commands in this document send JSON data via the WLED JSON API.
